HR600

Large area rotary mower / Superb power to weight ratio

Cut roughs, surrounds, and around obstacles effortlessly in all conditions with powerful HR600. A narrow transport width makes every area of the golf course accessible with zero maintenance decks and unrivaled operator comfort keeping you on cut and on course until the work is done.

Key Features

Low maintenance, direct drive hydraulic decks

Tilt sensor technology (TST) warns of unsafe working angle

Low weight for efficiency and fuel economy

Specifications

MOWER CUTTING WIDTH	137" (3.5 m)
MOWER HEIGHT OF CUT	1 - 4.75" (25 - 121 mm) in 0.25" (6.4 mm) increments
MOWER ENGINE	Kubota 65.2 HP (48.6 kW) Turbo Diesel
CUTTING CAPACITY	13.8 acres/hr at 10 mph (5.6 ha/hr. at 16 km/h)
TRANSPORT SPEED	15.5 mph (25 km/h)
FUEL/BATTERY CAPACITY (+RUN TIME)	20.4 gal. (77.1 L)
MOWER WARRANTY	2 Years

Specifications, while correct at time of publishing, may change without notice. Available in ultra low sulfur diesel countries only. Cab optional.

NUMBER AND SIZE	1 x 60" (1.52 m) front deck; 2 x 44" (1.12 m) wing units
BLADE MATERIAL	MARBAIN® boron alloy steel
DECK LIFT/LOWER	Individual via fingertip operated joysticks
WEIGHT TRANSFER	On demand electrically operated hydraulic weight transfer system
DECK CONSTRUCTION	11 gauge (3 mm) Strenx, high strength steel shell

Specifications, while correct at time of publishing, may change without notice. Available in ultra low sulfur diesel countries only. Cab optional.

TRACTION DRIVE	Hydrostatic closed loop parallel-cross-series SureTrac™ system
DECK DRIVE	Seven individual hydraulic motors with self lubricating integral bearings
HYDRAULIC SYSTEM	13.3 gal. (50.2 L) reservoir with 10 micron remote charge filters and suction screening at tank. Oil cooler in side by side radiator.
SERVICE BRAKES	Dynamic braking through traction system
PARKING BRAKES	Automatic wet parking brakes integrated into wheel motors
STEERING	Power Steering
MOWING SPEED	10 mph (16.4 km/h)
REVERSE SPEED	4 mph (6.4 km/h)
TYRES	Front Tyres: 26 x 12-12 tubeless 8 ply. Rear Tyres :20 x 10-8 tubeless 6 ply

Specifications, while correct at time of publishing, may change without notice. Available in ultra low sulfur diesel countries only. Cab optional.

WEIGHT	3900 lbs. (1769 kg), 4356 lbs. (1976 kg) with cab
LENGTH	143" (3.62 m) front deck down
HEIGHT (ROPS UP)	83" (2.1 m)
WHEEL BASE	64" (1.65 m)
TRANSPORT WIDTH	65" (1.67 m)
WORKING WIDTH	143" (3.63 m)
FLUID CAPACITIES	Coolant Sytem and Capacity: Side-by-side radiator/hydraulic oil cooler; pressurized; 2 gl. (7.6 L) capacity, 8.5 fins per inch
