SIDE-SHIFTING CONTOUR ROTARY MOWER / POWER, STRENGTH AND PRECISION AT YOUR COMMAND

OverviewKey FeaturesSpecificationsdownload

Cut around ponds, bunkers, and hazards with precision using the AR331 Side-Shifting rotary mower. Jake’s Signature Cut is combined with simple routine maintenance and quick adjustments to give you a mower that can cut all day and always operates with ease.

Key Features

ADAPTISHIFT™ SIDE SHIFTS DECKS AT YOUR COMMAND

TRUSTWORTHY KUBOTA® ENGINE

ZERO MAINTENANCE WET PARKING BRAKE

Specifications

  • Key Attributes

    MOWER CUTTING WIDTH72" (182.88 cm) featuring ADAPTISHIFT™ with up to 12" (30.48 cm) of offset
    MOWER HEIGHT OF CUT0.75-3.5" (19-88 mm)
    MOWER ENGINEKubota® 24.8 HP (18.6kW) diesel
    CUTTING CAPACITY4.5 acres/hr. at 6mph (1.83 ha/h at 10km/h)
    TRANSPORT SPEED8.7 mph (14 km/h)
    FUEL/BATTERY CAPACITY (+RUN TIME)7.6 gal. (28.7 L)
    MOWER WARRANTY2 Years
    Specifications, while correct at time of publishing, may change without notice.

  • Decks and Cutting Units

    NUMBER AND SIZE3 x 27" (68.58 cm) TrueDeck rotary cutting units
    BLADE MATERIALHardened, carbon steel alloy
    DECK LIFT/LOWERArmrest mounted joystick
    WEIGHT TRANSFERAdjustable hydraulic, electronically activated operator control
    DECK CONSTRUCTION9-gauge, stamped modular deck construction
    Specifications, while correct at time of publishing, may change without notice.


  • Traction, Brakes and Speed

    TRACTION DRIVEParallel-series"on demand" 3WD
    DECK DRIVEFixed displacement hydraulic
    HYDRAULIC SYSTEM8.7 gal. (33 L) capacity, full flow filtration (10 micron filter); GreensCare biodegradable oil.
    SERVICE BRAKESDynamic braking through hydrostatic drive
    PARKING BRAKESService-free electronic wet disc
    STEERINGHydraulic power steering with tilt wheel
    MOWING SPEED6.2 mph (10 km/h)
    REVERSE SPEED3.7 mph (6 km/h)
    TYRES
    Specifications, while correct at time of publishing, may change without notice.

  • Weight and Dimensions

    WEIGHT2004 lb. (909 kg)
    LENGTH122" (3.10 m)
    HEIGHT (ROPS UP)82" (2.06 m)
    WHEEL BASE61" (1.54 m)
    TRANSPORT WIDTH77" (1.96 m)
    WORKING WIDTH77" (1.95 m)
    FLUID CAPACITIESHydraulic System 8.7 gal. capacity, full flow filtration (10 micron filter); GreensCare biodegradable oil
    Specifications, while correct at time of publishing, may change without notice.
