Cushman

Tug 8K AC Electric

The newly designed, AC-powered Tug is built to help you pull through big tasks with increase efficiency and user-friendly features.

tugproduct 1
tugproduct2
tugproduct3
tugproduct5
Cushman Logo
OverviewKey FeaturesSpecifications

Take your towing up a notch. Built for one specific job, the Tug tow tractor gives your facility the power to pull loads that were previously unmovable. No matter the load, you can count on the Tug to pull its weight.

Powertrains:

  • 48V AC Electric Drivetrain
  • 650-Ib Vehicle Load Capacity
  • 8,000-Ib Vehicle Towing Capacity
  • 4.9-squft Cargo Deck

Key Features

48V AC electric drivetrain

Power to pull tons, literally.

tug_vehicledetailpage_feature1_720x450
tug_vehicledetailpage_feature2_720x450

Versatile towing connection

Accepts a variety of implements.

4.9-sq-ft Cargo deck

Bring tools and gear along.

tug_vehicledetailpage_feature3_720x450
tug_vehicledetailpage_feature4_720x450.jpg_77

Digital display

Speedometer/Hour Meter/State of Charge

Specifications

  • BODY & CHASSIS

    FRAMEWelded Steel w/ DuraShield™ Powder Coat
    BODY & FINISH4-way Embossed Diamond Pattern
    STANDARD COLORSafety Yellow

  • DIMENSIONS

    OVERALL LENGTH76.0 in (193 cm)
    OVERALL WIDTH34.5 in (88 cm)
    OVERALL HEIGHT37.0 in (94 cm)
    WHEEL BASE52.5 in (133 cm)
    WHEEL TRACKN/A Front / 29.7 in (75 cm) Rear
    CARGO DECK MATERIALHIP Board

  • POWER

    POWER SOURCE48V DC
    HORSEPOWER (KW)Continuous 6.7hp (5kw); Peak 15.4hp (11.5kw)
    ELECTRICAL SYSTEM48V
    BATTERY (QTY/TYPE)Six, 8V Deep Cycle
    BATTERY CHARGER48V DC On-Board, 1000W
    KEY OR PEDAL STARTPedal
    SPEED CONTROLLERAMP AC Programmable. SRO Capable
    DRIVE TRAINMotor Shaft Direct Drive GEAR SELECTION
    GEAR SELECTIONDash Mounted (Key Switch)
    REAR AXLE RATIO17.05:1

  • PERFORMANCE

    SEATING CAPACITY1-Person
    WEIGHT W/O BATTERIES508 lb (230 kg)
    CURB WEIGHT936 lb (425 kg)
    VEHICLE LOAD CAPACITY650 lbs (295 kg)
    TOWING CAPACITY8000 lb (3629 kg)
    OUTSIDE CLEARANCE CIRCLE9.0 ft (2.8 m)
    SPEED
    7.8 mph +/- 0.5 mph (12.6 kph +/- 0.8 kph)

  • STEERING & SUSPENSION

    STEERINGHandlebar
    SUSPENSIONTorsion Block (Front) / Coil Over Shock
    SERVICE BRAKE2-Wheel Hydraulic Drum
    PARKING BRAKETorsion Block (Front) / Coil Over Shock SERVICE BRAKE
    TIRESUSA Trail 4.80 x 8 (Load Range B)
