Connect

Jacobsen

Spray Star 1200 Spray Vehicle

Star 1200 product1

EFFICIENCY
Save time and money with the Spray Star 1200. The most accurate spray technology at your fingertips.

PRECISION
GPS-enabled with our state- of-the-art Star Command 3.0 ensures a precise application every time.

DURABILITY
Superior construction and materials combine to ensure industry-leading longevity across our product lines.

RELIABILITY
Family-owned since 1967, Smithco products are built to last. Great people make great products.

Exclusive Features : Industry Leading

While Standard Controls are available, the Spray Star 1200 features industry leading options such as the TeeJetTM Radion Rate Controller, Radion with Dyna-JetTM Pulse Width Modulation, or Smithco’s Star Command II providing consistently less than 2in/5cm nozzle spacing offering a 100% greater accuracy than our competitors.

  • Traction drive

Center mount engine and hydro-pump providing the ultimate in serviceability and balance. Hydrostat allows for constant engine RPM providing constant flow and pressure to the spray system for a consistent spray application.

  • Productivity

Optimum efficiency with largest capacity dedicated sprayer in its class providing a 200-gallon/757-liter low profile elliptical Polypropylene tank with lifetime warranty.

  • Ultra High Flow

The self-priming and corrosion resistant, HyproTM Stainless Steel Centrifugal Pump features 90gmp/341pm providing the capability for high flow applications with superior agitation. Making for a high performance, and cost-efficient pumping system.

  • Cab-Forward Design

Ergonomically designed for superior visibility, handling, and comfort, the Spray Star 1200’s cab-forward design makes the work simple, comfortable, and enjoyable.

Star command 3.0 features

James-Netz-c-7841-2-1024x683

No one matches our 9 years of experience developing the most precise application available for spraying chemicals on turf. With our Partner, TeeJet® Technologies, the Star Command 3.0 System features all of TeeJet’s® previous benefits available on every Star Command sprayer, as well as these exclusive new features:

TURN COMPENSATION corrects flow to keep application rates on target through turns as tight as 20 feet. It lets you avoid straight- line applications on contoured area or rates varying as much as 50% from the inside to the outside of a boom. That doubles the application rate on the inside and cuts the outside rate in half.

TEN INCH NOZZLE SPACING to cut off-target applications in half. This spacing also allows for more efficacy because of increased overlap of the spray patterns.

VIRTUAL, ON-SCREEN NOZZLE CONTROL. TeeJet’s® new job computers operate up to 100 nozzle sections that can be controlled individually. This eliminates the need for extra cabling and job-stopping failure of mechanical switches.

THE DYNAJET SYSTEM is also incorporated into the Aeros 9040 controller, eliminating extra cabling and separate controller.

TERRASTAR-C PRO significantly reduces Convergence Time, to as little as 90 seconds or less.

Specifications

  • ENGINE

    TYPEVanguard V-twin Air Cooled
    DISPLACEMENT896 cc
    RATED HORSEPOWER26 kw
    AIR CLEANERDouble Action air intake filtration Engine mounted cyclonic filtration system
    COOLINGAir Cooled
    LUBRICATIONFull Pressurized
    OIL FILTERFull Flow, Spin on type
    ELECTRICAL SYSTEM24 amp, with 12V 900 CCA battery, fuse protected
    FUEL CAPACITY37.9 L
  • TRACTION DRIVE

    TRACTION SYSTEMHydraulic power to two rear wheel drive
    HYDRAULIC SYSTEM19 L
    HYDRAULIC COOLINGFull flow filter with oil
  • TIRES, BRAKES AND STEERING

    TIRESFront: 20-10.00×10 Turf Rear: 24-13.00×12 Multi trac
    SERVICE BRAKESDynamic braking through hydrostatic transmission
    PARKING BRAKEAuto spring pressure release park brake Manual engagement to both rear wheels
    STEERINGSteering Hydraulic Power Steering with orbitrol motor. 15” steering wheel with tilt adjustment
  • SPEED

    TRANSPORT0-20 kph

  • SPRAY TANK

    CAPACITY757 L
    CONSTRUCTIONEliptical polyethylene with UV inhibitors. 16” hinged lid with built in locking device and nylon strainer basket
    FILTRATIONDownstream filtration 50 mesh strainer
    AGITATIONAgitator with 4 venturi volume boosters
    PUMPRocker switch operated. 10-70 gpm (36-225 lpm). 10-60 psi (0-7.4 bar). Stainless high volume centrifugal with silicon carbide seals.
    LUBRICATIONFull Pressurized
    OIL FILTERFull Flow, Spin on type
    ELECTRICAL SYSTEM24 amp, with 12V 900 CCA battery, fuse protected
    FUEL CAPACITY10 gallons
  • SPRAY PERFORMANCE

    APPLICATION RATES20-220 gallons per acre 0.5-5 gallons per 1000 sq.ft.
    PRODUCTION RATE6.4 acres/hour @ 3.5 mph Up to 75 acres per day
  • WEIGHTS AND DIMENSIONS

    WEIGHTDry – 1877 lbs Loaded – 3626 lbs
    LENGTH127”
    WIDTH65”
    HEIGHT78”
    WHEELBASE68”
