The Campey™ SPEEDRESSER™ are bulk drop-spreader designed to handle all top dressing materials. The 4 flotation tyres on pivoting axle minimise the risk of turf damage and compaction. Ideal for golf courses and sports fields use, both with private clubs, local authorities and contractors. The SPEEDRESSERTM requires a tractor of at least 30hp, and is driven hydraulically from the tractor via an agitator and twin rollers. The high work rate enables the spreading of dressings up to depths of 2mm-75mm in one pass.
Specifications
Speedresser 18H
SPREADING WIDTH 1.80m OVERALL WIDTH 2.10m BODY LENGTH 3.00m with drawbar – 2.00m without HOPPER CAPACITY 3.25m³ LOADING HEIGHT 1.75m GROSS WEIGHT 5,500kg WEIGHT (UNLADEN) 1,050kg TRACTOR REQUIREMENT 50hp +. Spool valve. Pick up hitch/drawbar TYRES 4 x Ultra Trac 26.5 x 14 x 12 OPERATING SPEED Up to 12mph (18kph) Speedresser 24 H
SPREADING WIDTH 2.40m OVERALL WIDTH 2.65m BODY LENGTH 2.30m HOPPER CAPACITY 5.75m³ LOADING HEIGHT 2.00m GROSS WEIGHT 9,250kg WEIGHT (UNLADEN) 2,250kg TRACTOR REQUIREMENT 75hp +. Hitch/drawbar and spool valve TYRES 4 x Flotation tyres – 15.5 x 14 ply OPERATING SPEED Up to 12mph (18kph)
