Refresher® Oasis

Industry-leading can capacity and your choice of the industry's only 72-Volt AC electric drivetrain or 13.5-hp EFI gas engine.

refresheroasis_EFIGas product1
refresheroasisEFI Gas product2
refresheroasisEFI Gas product3
refresheroasisEFI Gas product4
Cushman Logo
OverviewKey FeaturesSpecificationsDownload

The Refresher Oasis was built for long days and busy events. With its industry-leading can capacity and enough merchandising space for your most popular items, stopping to restock is yesterday’s problem. Now available in a 72-Volt AC electric drivetrain or a 13.5hp EFI gas engine.

POWERTRAINS

REFRESHER OASIS EFI GAS
REFRESHER OASIS 72-VOLT
– 13.5-hp EFI Gas Engine– 72-Volt AC Electric
– 4 Cold Storage Drawers– 50-mile range on a single charge
– 500-Can Capacity– 4 Cold Storage Drawers
– 6.7-cu-ft of Merchandising– 500-Can Capacity
– 3.4-cu-ft Trash Capacity– 3.4-cu-ft Trash Capacity
– 12.1-sq-ft Work Space– 12.1-sq-ft Work Space

Key Features

500-can capacity

Carry more beverages and spend less time restocking.

refresheroasis_vehicledetailpage_feature1_720x450
refresheroasis_vehicledetailpage_feature2_720x450

our beverage compartments

Organized for fast service.

Wraparound endcap counter

Room to stage purchases and complete transactions.

refresheroasis_vehicledetailpage_feature3_720x450
refresheroasis_vehicledetailpage_feature4_720x450

6.7-cu-ft of merchandising

Offer more point of sale options.

ECO-FRIENDLY RECEPTACLES

Separate trash and recycling.

refresheroasis_vehicledetailpage_feature5_720x450
refresheroasis_vehicledetailpage_feature6_720x450

PROTECTIVE CANOPY

Shield customers and employees from the elements.

Specifications

  • BODY & CHASSIS

     Refresher Oasis EFI GasRefresher Oasis 72-Volt
    FRAMEWelded Steel w/ DuraShield™ Powder CoatWelded Steel w/ DuraShield™ Powder Coat
    BODY & FINISHInjection Molded TPO, PaintedInjection Molded TPO, Painted
    STANDARD COLORForest GreenForest Green

  • DIMENSIONS

     Refresher Oasis EFI GasRefresher Oasis 72-Volt
    OVERALL LENGTH117.0 in (297.18 cm)117.0 in (297.18 cm)
    OVERALL WIDTH50.8 in (129.032 cm)50.8 in (129.032 cm)
    OVERALL HEIGHT47.4 in (120.40 cm) (No Canopy) 73.3 in (1866 cm) (Canopy)47.4 (120.40 cm) (No Canopy) 76.0in (186.18 cm) (Canopy)
    WHEEL BASE76.0 in (193.04 cm)76.0 in (193.04 cm)
    WHEEL TRACK35.0 in (89 cm) Front 38.5 in (98 cm) Rear35.0 in (89 cm) Front 38.5 in (98 cm) Rear
    GROUND CLEARANCE3.5 in (9.0 cm)3.5 in (9.0 cm)
    CARGO DECK CAPACITY6.7 cu ft (.19 m3) Merchandising 500 Can Beverage Capacity6.7 cu ft (.19 m3) Merchandising 500 Can Beverage Capacity
    CARGO DECK MATERIAL5000 Series Aluminum - Super Durable TGIC Polyester Powder Coating5000 Series Aluminum - Super Durable TGIC Polyester Powder Coating

  • POWER

    Refresher Oasis EFI GasRefresher Oasis 72-Volt
    POWER SOURCE4 cycle, 24.5 cu in (401 cc)72-Volts
    VALVE TRAINSingle Cylinder OHV-
    HORSEPOWER (KW)13.5 hp (10.1 kW)22.4HP (16.7 kW) - Measured at Peark Torque
    ELECTRICAL SYSTEMStarter/Generator, Solid State Regulator72 Volt
    BATTERY (QTY/TYPE)One, 12V Maintenance FreeNine 8-Volt Deep Cycle
    BATTERY CHARGER-900 Watt 72V DC
    KEY OR PEDAL STARTPedalPedal
    AIR CLEANERIndustrial Rated Dry Filter-
    LUBRICATIONPressurized Oil System-
    OIL FILTERSpin-On-
    COOLING SYSTEMAir CooledMotor Shaft Direct Drive
    FUEL CAPACITY6.65 Gallon (25.2 L) Tank-
    DRIVE TRAINContinuously Variable Transmission (CVT)Motor Shaft Direct Drive
    KEY OR PEDAL STARTPedalPedal
    GEAR SELECTIONForward - ReverseForward-Neutral-Reverse
    REAR AXLE RATIO16.53:1 (Forward) 16.81:1 (Reverse)17:1

  • PERFORMANCE

     Refresher Oasis EFI GasRefresher Oasis 72-Volt
    SEATING CAPACITY2-Person2-Person
    WEIGHT W/O BATTERIES1135 lb (514.83 kg)1105 lb (501.22kg)
    CURB WEIGHT1175 lb (532.971 kg)1670 lb (757.50 kg)
    VEHICLE LOAD CAPACITY1066 lb (483 kg)1066 lb (483 kg)
    OUTSIDE CLEARANCE CIRCLE21.5 ft (6.5 m)21.5 ft (6.5 m)
    SPEED11 mph ± 0.5 mph (17.7 kph ± 0.8 kph)11 mph ± 0.5 mph (17.7 kph ± 0.8 kph) Forward 10 mph ± 0.5 mph (16 kph ± 0.8 kph) Reverse

  • STEERING & SUSPENSION

     Refresher Oasis EFI GasRefresher Oasis 72-Volt
    STEERINGSelf-Compensating Rack & PinionSelf-Compensating Rack & Pinion
    SUSPENSIONLeaf Springs w/ Hydraulic Shock Absorbers (Front) Leaf Springs w/ Hydraulic Shock Absorbers (Rear)Leaf Springs w/ Hydraulic Shock Absorbers (Front) Leaf Springs w/ Hydraulic Shock Absorbers (Rear)
    SERVICE BRAKERear Wheel Mechanical Self-Adjusting DrumRear Wheel Mechanical Self-Adjusting Drum
    PARKING BRAKESelf-Compensating Single Point EngagementSelf-Compensating Single Point Engagement
    TIRES18 x 8.5 – 818 x 8.5 – 8

Download

Refresher Oasis Brochure
