PAR+ES Controller
Easy to Use. Proven Performance.
Boasting advanced technology, our updated PAR+ES Satellite Controllers feature IFX Satellite Boards that take communicating with Rain Bird’s Integrated Control Interface Plus (ICI+) and IC System™ to the next level.
Now you can upgrade your satellite system using the same wire path while enjoying 72-station capability, unlimited programs with Central Control, premium surge protection, extensive diagnostics, and a best-in-class pedestal enclosure. And, with forward-thinking Timeless Compatibility™, it’s the best of both worlds for today and tomorrow. Want even more flexibility? Our exclusive ICI+LINK and LINK 900 MHz radios give you greater design options without the need for additional communication wires or license requirements.
Key Features
Large, raised control buttons with clear, descriptive icons and a high-contrast Liquid Crystal Display (LCD) panel make programming easy — even for the novice. Lights indicate active schedules and central control status, while copy-paste function speeds the programming process. An angled keypad aids visibility as well as water drainage and makes the PAR+ES controller extremely easy to use.
Download
Specifications
Specs
STATION CAPACITY
72 stations, up to 16 solenoids operating simultaneously (60 Hz) ELECTRICAL INPUT (50/60 Hz) 117 VAC Nominal 98 to 132 VAC220 VAC Nominal 208 to 232 VAC240 VAC Nominal 225 to 255 VACELECTRICAL OUTPUT 26.5 VAC, 5.25 AMP STATION LOAD CAPACITY Up to four (4) 24 VAC, seven (7) VA solenoids per station PROGRAMS No limit with Rain Bird Central Control Systems. Six (6) automatic (8 start times each) and two (2) manual in standalone mode. WATER BUDGET 0 to 200% in 10% increments. STATION RUNTIMES 1 to 120 minutes, in 1-minute increments. LANGUAGES English, French, German, Italian, Japanese, Portuguese, Spanish and Dutch.GROUNDING REQUIREMENTS Less than 10 ohms CERTIFICATIONS cULus [US and Canada], FCC Part 15b [US], CAN ICES-3(B)/NMB-3(B) [Canada], CE [European Union]. Dimensions
WIDTH 17" (43.2 cm) HEIGHT 34 ¾" (88 cm) DEPTH 21" (53.4 cm)
