hauler® Pro

Bring a new level of productivity to each workday with a powerful 72V AC electric drivetrain and 50 mile range, plus optional IntelliBrake technology.

It’s time to raise your expectations of electric-powered vehicles. With a 72V AC drivetrain that offers the hauling and hillclimbing power you need, the Hauler® PRO has the capacity to outperform its gas-powered competitors. Couple that with optional IntelliBrake™ technology, silent operation and zero-emissions, and the Hauler PRO quietly turns skeptics into believers.

Hauler Pro Electric Powertrains :

72V AC Electric Drivetrain
1,200-Ib vehicle Load Capacity
800-Ib Bed Load Capacity
1,500-Ib Towing Capacity
12-cu-ft Cargo Bed
2-Passenger Seating

Key Features

72V AC Electric Drivetrain

Unrivaled AC power, efficiency and a 50-mile range.

haulerpro_vehicledetailpage_feature1_720x450

haulerpro_vehicledetailpage_feature2_720x450

Integrated Tie-Down System

A series of tie-down locations make it easy to secure maintenance equipment or loose loads.

12-cu-ft Cargo Bed

Generous, customizable space for tools and supplies.

haulerpro_vehicledetailpage_feature3_720x450

haulerpro_vehicledetailpage_feature4_720x450

Optional Bed Divider

Highly customizable bed to maximize your load.

Highly Functional Dashboard

Industry-leading storage and control at your fingertips.

haulerpro_vehicledetailpage_feature5_720x450_0

haulerpro_vehicledetailpage_feature6_720x450

On-Board Charger

The flexibility to charge from anywhere.

Specifications

BODY & CHASSIS
FRAME Welded Steel DuraShield™ Powder Coat
BODY & FINISH Injection Molded TPO
STANDARD COLOR Forest Green / Patriot Blue

FRAME	Welded Steel DuraShield™ Powder Coat
BODY & FINISH	Injection Molded TPO
STANDARD COLOR	Forest Green / Patriot Blue

OVERALL LENGTH	115 in (292.1cm)
OVERALL WIDTH	49.4 in (125.5 cm)
OVERALL HEIGHT	46.5 in (118 cm) (w/o Roof) 70.5 in (179.1 cm) (w/ Struts & Roof)
WHEEL BASE	76 in (193 cm)
WHEEL TRACK	35 in (88.9 cm) Front 38.5 in (97.8 cm) Rear
GROUND CLEARANCE	4.5 in (11.4 cm)
CARGO DECK CAPACITY	12-cu-ft (0.34 m3)
CARGO DECK MATERIAL	Roto-Molded Polyethylene

POWER SOURCE	72V DC
HORSEPOWER (KW)	22.4HP (16.7 kW) - Measured at Peak Torque
ELECTRICAL SYSTEM	72V
BATTERY (QTY/TYPE)	Nine, 8V Deep Cycle
BATTERY CHARGER	900 Watt 72V DC
KEY OR PEDAL START	Pedal
SPEED CONTROLLER	350 Amp AC
DRIVE TRAIN	Motor Shaft Direct Drive
TRANSAXLE	Differential w/ Helical Gears
GEAR SELECTION	Forward-Neutral-Reverse
REAR AXLE RATIO	17:01

SEATING CAPACITY	2-Person
WEIGHT W/O BATTERIES	910 lb (413 kg)
CURB WEIGHT	1475 lb (669 kg)
VEHICLE LOAD CAPACITY	1200 lb (544 kg)
BED LOAD CAPACITY	800 lb (363 kg)
TOWING CAPACITY	1500 lb (680 kg) max
OUTSIDE CLEARANCE CIRCLE	21.5 ft (6.6 m)
SPEED	14.5 mph ± .05 mph (23.3 kph ± 0.8 kph)

STEERING	Self-Compensating Rack & Pinion
SUSPENSION	Leaf Springs w/ Hydraulic Shock Absorbers (Front) Leaf Springs w/ Hydraulic Shock Absorbers (Rear)
SERVICE BRAKE	Rear Wheel Mechanical, Self-Adjusting Drum
PARKING BRAKE	Self-Compensating,Single-Point Engagement
TIRES	18 x 8.5-8
