Eclipse 360 Elite
Lithium ride-on reel mower / Our Lithium green mower
The latest Lithium-lon battery, outstanding technology, and a hydraulic-free design makes the Eclipse 360 electric greens mower the greenest, quietest and highest quality Jake cut available for your golf course.
Key Features
Jake greatest cutting and run range
Elite Lithium battery
No hydraulic oil
Unique swing out center cutting unit for ease of service
Specifications
Key Attributes
MOWER CUTTING WIDTH 63” (1.6 m) MOWER HEIGHT OF CUT 0.062” - 0.438” (1.6 - 11.1 mm) BLADES PER REEL 7, 9, 11 or 15 FUEL/BATTERY CAPACITY (+RUN TIME) Lithium Battery - 250 Ah lithium pack, 12.2kW/hrs. MOWER ENGINE Lithium Battery with onboard charger CUTTING CAPACITY Cut 143K sq. ft (12,449 sq. m) of greens + 6 miles (9.65 km) of transport with groomers and brushes installed MOWER WARRANTY 2 Years Reels and Blades
NUMBER AND SIZE 3 x 22” (55.88 cm) reels; 5” (127 mm) diameter BLADE MATERIAL Hardened, high manganese carbon steel CUTTING UNIT LIFT New Long Life linear actuator CUTTING FREQUENCY 0.036” - 0.250” (0.91 mm - 6.35 mm) with 15 blade reel, electronically adjustable Traction, Brakes and Speed
TRACTION DRIVE Front / 2WD - AC; 4.4 HP (3.3 kW) continuous (Optional 3WD – PM; 3.2 HP (2.4 kW)) REEL DRIVE One brushless DC motor per reel 1.3 HP (0.97 kW) continuous HYDRAULIC SYSTEM No Hydraulic Oil SERVICE BRAKES Dynamic regenerative braking system PARKING BRAKES Automatic electro-magnetic multi-plate STEERING Variable ratio Drive-by-wire steering with feedback control MOWING SPEED 0 - 5.0 mph (0 - 8.9 kph); electronically adjustable max speed TRANSPORT SPEED 0 - 9.0 mph (0 - 14.5 kph) electronically adjustable max speed TYRES 18 x 10.5 x 8 4-ply Weight and Dimensions
WEIGHT TBD LENGTH (LESS CATCHERS) 101" (2.56 m) (with Catchers) OVERALL HEIGHT INCLUDING ROPS 79.3" (2.01 m) WHEEL BASE 52" (1.32 m) TRANSPORT WIDTH 67.7" (1.72 m) WORKING WIDTH 67.7" (1.72 m)
